Tubing Services

TruScan uses top of the line EMI (no radiation or gamma rays) inspection equipment that is the most accurate, detailed, and reliable on the market today. It features a split channel that consists of two rubbers that make a seal on the tubing with constant air pressure feeding through. Any loss of the compressed air is an effective way to detect a hole or a split on the tubing.

Specifications:

Contact shoes that help to pick up transverse cracks, small and large pitting, holes, splits, and monitoring for wall loss due to rod wear, corrosion etc.

Tubing inspection capacity: 2⅜" to 3½" (with coupling).

Inspection speed range: 40‐250 ft./min.

Estimated time to calibrate: 10‐15 minutes.

PC‐Based electronics: Flaw detection with solid state hall effects technology includes solid state hall effects with exclusive TRUE‐WALL™ wall thickness monitoring system, SPLIT‐Check pneumatic longitudinal split and hole detection system, and computerized data acquisition system.

Inspection head: Exclusive “TFD” (True Flaw Detection) system with solid state hall effect sensors.

Software features: Windows® based software with digital charts and a data acquisition spreadsheet program for documentation, i.e. reject data, joint number, etc. Each section of pipe is numbered and stored to disk. Well Profile Report indicates problem areas in string and is an excellent string management tool for future reference.

TruScan offers safe, efficient, and cost-effective tubing testing services in West Texas and New Mexico. Our experienced testers will ensure that your tubing is properly tested to your preferred pressure (up to 10,000psi), to detect holes, high pressure splits, weak wall, and any faulty connections.

We have the capability to test 2⅜", 2⅞ʺ and 3½ʺ bare and IPC tubing.
